CombiScan® 500 Analyzer

《Specification 》:

Article Number: A 95 005

《Product Introduce 》:

CombiScan® 500 is a semi automated urine test strip analyzer for use with CombiScreen® 11  SYS or 11  SYS PLUS test strips. It is designed for bigger laboratories and for hospitals.

Features & Functions - A 95 005

Analyticon Logo

• Modern CCD technology

Interface for barcode reader and keyboard

Automatic test strip recognition and standby

Variable format selection for printout of test results and time/data

Integrated printer

Automatic transport, measurement of test strips

Bi-directional interface for laboratory and ­hospital EDP



Technical Data

Image sensor: CCD technology
Throughput: 500 strips/hour
Display: 4 x 24 character LCD
Languages: English, German, French, Hungarian, Spanish
Output options: Units: SI, Conventional, Arbitrary



Low noise, built-in thermotransfer printer
Paper size: 57 mm x ø 50 mm
Memory: Last 999 results
Interfaces: RS 232 and DIN 5
Ext. Power Ad.: 7,5 V DC/3 A



• Keyboard

• Barcode reader

Urine test strips CombiScreen® Classic

• Paper roll 57 mm



• CombiScan 100/500 Flyer english
